E30
Enviro Fireplaces
The E30 Gas Fireplace Insert
Specs
Additional Specs
Jet Systems
More Details
Features
Viewing Area
24 3⁄8" W x 14" H
Heating Area
1,700 ft²
Max Input BTU (NG)
33,000
Min Output BTU
11,800
P4 Efficiency
71.4%
Glass Size
26 1⁄4" W x 16" H
Convection Fan
150 CFM
Install Dimensions
27 7⁄8” W x 19 7⁄8” H
Install Depth Range
16 7⁄16” - 18 5⁄8”
###additionalSpecs###
###jetsystems###
Features
- Clean face look - no louvers.
- SIT Valve 820 (standing pilot).
- Easy-access burner switch.
- Up to 50% turn down valve.
- Clear View Safety Screen
Options
- Borderview Surround:
Powder Coated Grey
40" W x 26 1⁄8" H - Borderview Plus 4S Surround:
Powder Coated Grey
40" W x 31" H - Cast Plus Surround
39 3⁄8" W x 24 3⁄4" H - Cast Plus O/S Surround:
50" W x 30" H - Contemporary Surround:
39 7⁄8" W x 25" H - Designer Surround:
Powder Coated Grey | Powder Coated Silver
38 5⁄8" W x 24 1⁄2" H - Extruded Surround:
39 3⁄4" W x 25 1⁄8" H - Extruded 4S Surround:
39 3⁄4" W x 31 1⁄2" H - Extruded O/S Surround:
39 3⁄4" W x 29" H - Forgeworks Face:
Midnight Bronze
40" W x 26 1⁄8" H - Galiano Surround:
Brushed Graphite
39 7⁄8" W x 25" H - Modern Surround:
39 7⁄8" W x 25" H - O/S Contemporary Surround:
39 7⁄8" W x 29" H - Slim Surround:
33 1⁄4" W x 22" H - Trimmable Filler Panel:
46" W x 38" H - Available Liners:
Black Enameled (Included) | Brick Fluted | Grey Brick Herringbone | Ledgestone Steel (Included)
